Chemical Scrubber Odor Control Systems

Packaged Chemical Scrubber is a multi-stage high efficiency scrubber capable of promoting different chemical reactions in each stage and targeting a range of different compounds found in municipal Wastewater Treatment Plants and Pump Stations.

Odor Control Systems

Place your order at AQUAANALYTIC, Dubai.
We will quickly deliver your order to any country.

The system is designed to be compact and low profile, enabling indoor or outdoor installation. IMS’ chemical scrubber system is completely factory assembled for ease of installation treating airflow capacities up to 40,000 m³/h in a single system. IMS’ CPS odor control system is a ‘once-through’, two-stage absorption system consisting of a gas conditioning / pre-treatment stage followed by two vertical co-current/counter-current gas absorption sections.

Chemical Scrubber Odor Control Systems

Chemical Scrubber Odor Control Systems

ADVANTAGES
  • Reliable in the long term with robust design
  • Minimized footprint and height required for the scrubber system and associated pumps and piping and ductwork.
  • Provides flexibility to customize the chemistry of each stage, to optimize the operating chemistry for actual plant odors, and to respond to process variations.
  • Will make optimum use of chemical and minimize chemical costs.
  • Will be delivered and installed quickly and smoothly, with minimum construction and installation cost and time.
  • Will not require downtime for routine calibration and maintenance.
  • Provides maximum value measured by effective odor control with minimum problems, maintenance and operating cost.

COMPONENTS
  • FRP Air Supply Fan
  • FRP Vessel Inlet Transition Piece
  • FRP Two-Stage Scrubber System
  • Two Counter-Current Stage Gas Absorption System
  • Two Integral Chemical Sumps
  • Packing Media, Nozzles and Mist Eliminator
  • Internal Piping and Access Doors
  • Exhaust Stack
  • PP Chemical Recirculation Pumps (vertical seal-less pumps)
  • NaOH and NaOCl Metering Pumps
  • Control Panel with Motor Starters
  • pH, ORP and Level Controls
  • Pressure & Differential Pressure Gauges
