VNX30-CDIT & 15-CDIT Module Ionpure
Produces high-purity water from a feed water nearly two times worse than typical CEDI products
Place your order at AQUAANALYTIC, Dubai.
We will quickly deliver your order to any country.
VNX-CDIT modules are unlike any other within the VNX family. These modules can tolerate up to 4 ppm feedwater hardness as CaCO3, up to 2 ppm feedwater silica as SiO2, and up to 100 μS/cm feedwater conductivity equivalent (FCE). To put it simply, these modules are optimized to provide high-purity water typically from a single-pass reverse osmosis (RO) feedwater supply with up to 90% recovery. Other modules, like the VNX-55, are limited to 1 ppm feedwater hardness, 1 ppm feedwater silica, and 40 μS/cm FCE.
VNX30-CDIT & 15-CDIT Module Ionpure
FEATURES:
- 4 ppm as CaCO3 max feed water hardness
- 2 ppm as SiO2 max feed water silica
- Expanded CO2 removal capabilities
- In most cases can operate on single pass RO permeate
- Thin cell technology optimized for feed water hardness tolerance
- No need for acid/caustic, neutralization systems or tank exchanges
- Junction box for convenient and safe power connections
- Available as 30 gpm (6.8 m³/h) or 15 gpm (3.4 m³/h) nominal flow rates
IP-VNX15CDIT-2
- Product Flow, minimum gpm (m³/h): 7.5 (1.7)
- Product Flow, nominal gpm (m³/h): 15 (3.4)
- Product Flow, nominal gpm (m³/h): 22.5 (5.1)
IP-VNX30CDIT-2
- Product Flow, minimum gpm (m³/h): 15 (3.4)
- Product Flow, nominal gpm (m³/h): 30 (6.8)
- Product Flow, nominal gpm (m³/h): 45 (10.2)
